Analysis and Determination of Technological Trends of the Development of an Afterburning Chamber of Turbofan Engines

Figures & Tables

Aircraft	Purpose	Year in Service	Engines (Number & Type)	Engine Weight (kg)	Thrust (AFB), kN	Max Takeoff Weight (kg)	Thrust-to-Weight Ratio (AFB)	SFC (AFB), kg/N·h
T-38 Talon	CTA	1961	2 × J85-GE-5A	265	17.12	5670	6.58	0.224
F-5B	CTA	1964	2 × J85-GE-13	271	18.15	9298	6.82	0.227
Su-15	FI	1967	2 × Tumansky R-13	1205	64.7	17900	5.47	0.213
SEPECAT Jaguar	AA	1973	2 × Adour Mk 102	700	30.89	15700	4.49	0.265
F-15 Eagle	F	1976	2 × F100	1375	106	30845	7.85	0.2161
F-16 Fighting Falcon	MRF	1978	1 × F100	1375	106	19200	7.85	0.2161
Tornado	MRFB	1979	2 × RB199	900	71.13	28000	8.05	0.2651
F/A-18A/B Hornet	MRF	1983	2 × F404	980	71.2	25400	7.40	0.177
MiG-29	MRF	1983	2 × RD-33-2S	1040	83	18000	8.13	0.214
Mirage 2000	MRF	1984	SNECMA M53	1470	88.2	17000	6.11	0.209
Su-27	F	1985	2 × AL-31F	1530	122.4	30450	8.15	0.196
B-1B Lancer	SB	1986	4 × F101	1815	133.4	216400	7.49	0.2243
AIDC F-CK-1 Ching-kuo	MRF	1994	2 × F125	900	42	12200	4.75	0.21
Rafale	MRF	2001	2 × M88	897	75.62	24500	8.59	0.1733
Eurofighter Typhoon	MRF	2003	2 × EJ200	989	90	23500	9.27	0.1764
F-22 Raptor	MRF	2005	2 × F-119	1769	155.6	38000	8.96	0.221
Hongdu L-15	CTA	2013	2 × AI-222-25F	440	42	9500	9.73	0.19
Su-35S	MRF	2014	2 × AL-41F1C	1608	140	34500	8.87	0.192
HAL Tejas	MRF	2015	1 × GTX-35VS	1180	81	15500	6.99	0.207
F-35 Lightning II	MRF	2015	1 × F-135	1701	191.3	31751	11.46	0.198
Mitsubishi X-2 Shinshin	F	2016	2xIHI XF-5	1420	122	-	8.75	-
Su-57	MRF	2020	2 × AL-41F1	1700	160	37000	9.59	0.19
