FIGURE 1.
FIGURE 2.
Analysis results for a point-access panel building
| Waste category | Quantity of waste | Recyclability [yes/no] | |
|---|---|---|---|
| per whole building [t] | per 1 m3 built-up space [t·m−3] | ||
| Foundation construction of which | 276.92978 | 0.06022 | – |
| 17 01 01 Concrete | 272.16255 | 0.05918 | yes |
| 17 03 02 Bituminous mixtures | 4.73030 | 0.00103 | no |
| 17 02 03 Plastic | 0.03693 | 0.00001 | no |
| Perimeter casing of which | 362.18580 | 0.07876 | – |
| 17 01 01 Concrete | 311.36000 | 0.06771 | yes |
| 17 01 01 Iron and steel (reinforcement) | 1.65000 | 0.00036 | yes |
| 17 01 07 Mixtures of bricks | 41.00656 | 0.00892 | yes |
| 17 06 04 Insulation materials | 8.16924 | 0.00178 | no |
| Reinforced concrete structures of which | 1,060.44003 | 0.23060 | – |
| 17 01 01 Concrete | 875.38800 | 0.19036 | yes |
| 17 01 01 Iron and steel (reinforcement) | 27.55200 | 0.00599 | yes |
| 17 01 01 Mixtures (interior plaster) | 157.50003 | 0.03425 | yes |
| Floor construction of which | 151.29183 | 0.03290 | – |
| 17 01 01 Concrete | 136.30226 | 0.02964 | yes |
| 17 01 01 Iron and steel (reinforcement) | 5.66373 | 0.00123 | yes |
| 17 01 07 Mixtures of tiles | 3.88752 | 0.00085 | yes |
| 17 02 01 Wood | 2.97250 | 0.00065 | no |
| 17 06 04 Pure polystyrene | 0.12990 | 0.00003 | no |
| 20 03 07 PVC flooring | 1.93612 | 0.00042 | no |
| 20 03 07 Carpets | 0.39980 | 0.00009 | no |
| Brick core of which | 29.45596 | 0.00641 | – |
| 17 01 07 Mixtures of bricks | 21.54065 | 0.00468 | yes |
| 17 01 07 Mixtures of tiles | 7.91531 | 0.00172 | yes |
| Facade fillings of which | 7.87681 | 0.00171 | – |
| 17 09 04 Wood + glass | 2.07200 | 0.00045 | yes |
| 17 09 04 Plastic + glass | 2.31261 | 0.00050 | yes |
| 17 04 05 Iron and steel (doors) | 3.49220 | 0.00076 | yes |
| Roofing of which | 25.11277 | 0.00546 | – |
| 17 03 02 Bituminous mixtures | 3.00877 | 0.00065 | no |
| 17 05 04 Soils and stones | 15.55025 | 0.00338 | yes |
| 17 01 02 Aerated concrete | 6.55375 | 0.00143 | no |
| Total amount of monitored waste | 1,913.29298 | 0.41606 | – |
Input data of a point-access panel building (T06B-KDU)
| Specification | Value | Specification | Value |
|---|---|---|---|
| Number of stories | 4 + 1 | Length [m] | 18.74 |
| Number of tracts | 5 | Width [m] | 16.40 |
| Thermal insulation of the building (yes/no) | yes | Thickness of thermal insulation [m] | 0.14 |
| Paving area [m2] | 171.06 | Built-up area of one story [m2] | 307.34 |
| PVC area [m2] | 595.95 | Built-up space [m3] | 4,598.65 |
| Carpet area [m2] | 198.65 | Facade area [m2] | 580.16 |
| Parquet floor area [m2] | 256.80 | Number of residential units per floor | 4 |
Waste recycling/disposal costs, source of unit cost data
| Type of waste | Unit waste recycling//disposal costs [EUR/t] | Quantity [t] | Total costs [EUR] |
|---|---|---|---|
| 17 01 01 Lightly reinforced concrete, piece size up to 1,600 cm2 | 12.61 | 1,787.57857 | 22,535.49 |
| 17 01 02 Aerated concrete | 20.13 | 6.55375 | 131.93 |
| 17 01 07 Mixed waste concrete, bricks, tiles, and ceramic products, piece size up to 1600 cm2 | 18.48 | 74.35004 | 1,374.23 |
| 17 02 01 Wood | 62.97 | 2.97250 | 187.19 |
| 17 02 03 Plastic | 240.62 | 0.03693 | 8.89 |
| 20 03 07 PVC floor covering | 240.62 | 1.93612 | 465.87 |
| 20 03 07 Carpets | 240.62 | 0.39980 | 96.20 |
| 17 03 02 Bitumen strips | 240.62 | 7.73907 | 1,862.17 |
| 17 05 04 Soils and stones | 18.05 | 15.55025 | 280.63 |
| 17 06 04 Polystyrene | 240.62 | 8.29914 | 1,996.93 |
| 17 09 04 Wood + glass | 114.35 | 2.07200 | 236.94 |
| 17 09 04 Plastic + glass | 114.35 | 2.31261 | 264.46 |
| 17 04 05 Iron scrap over 4 mm thick | −133.16 | 3.49220 | −465.01 |
| Total | 1,913.29298 | 28,975.91 |
Recyclability of generated waste
| Waste | Quantity | |
|---|---|---|
| [t] | [%] | |
| Recyclable | 1,885.35567 | 98.54 |
| Non-recyclable | 27.93731 | 1.46 |
