Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
Figure 7
Figure 8
Elements present in the AA8090 material [8]_
| Composition | Li | Cu | Mg | Fe | Zn | Ti | Zr | Cr | Mn | Si | Al |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Weight (%) | 2.6 | 1.3 | 0.6 | 0.3 | 0.25 | 0.1 | 0.01 | 0.1 | 0.1 | 0.2 | Bal. |
Wear test parameters_
| Parameters | Level 1 | Level 2 | Level 3 |
|---|---|---|---|
| Load (N) | 10 | 20 | 30 |
| Sliding speed (m/s) | 0.5 | 1 | 1.5 |
| Sliding distance (m) | 1,000 | 1,000 | 1,000 |
Characteristics of the AA8090 material [8]_
| Details | Values |
|---|---|
| Density (g/cm3) | 2.54 |
| Hardness (HV) | 158 |
| Melting point (°C) | 600 |
| Modulus of elasticity (GPa) | 77 |
| Tensile strength (MPa) | 515 |
Characteristics of the CeO2 particles [14]_
| Details | Values |
|---|---|
| Density (g/cm3) | 7.6 |
| Melting point (°C) | 2,340 |
| Vickers hardness (MPa) | 270 |
| Young’s modulus (GPa) | 34 |
| Molecular weight | 172.12 |
Composite design details_
| Composites | AA8090 (wt%) | CeO2 (wt%) |
|---|---|---|
| AA8090 | 100 | 0 |
| AA8090/1.5 wt% CeO2 | 98.5 | 1.5 |
| AA8090/3.0 wt% CeO2 | 97 | 3 |
| AA8090/4.5 wt% CeO2 | 95.5 | 4.5 |
