Figure 1.
Figure 2.
Measurements of Pratylenchus penetrans from artichokes in Vietnam_ All measurements are in μm (except for ratio) and in the form: mean ± s_d_ (range)
| Characters | Pratylenchus penetrans (Cobb, 1917; Filipjev & Schuurmans Stekhoven, 1941) | |
|---|---|---|
| Sex | Female | Male |
| n | 10 | 10 |
| a | 24 ± 2.1 (21–27) | 27 ± 1.8 (24–30) |
| b | 6.2 ± 0.2 (5.9–6.5) | 5.7 ± 0.4 (5.3–6.2) |
| b′ | 3.9 ± 0.1 (3.7–4.1) | 3.8 ± 0.2 (3.4–4.2) |
| c | 17± 0.9 (15.7–18.8) | 18.1 ± 1.4 (16.5–21) |
| c′ | 2.3 ± 0.1 (2.1–2.5) | 2.2 ± 0.1 (2–2.4) |
| o | 17.4 ± 1.6 (15.8–20) | 18.9 ± 2.1 (15.1–22) |
| Body length (L) | 502 ± 23 (446–528) | 441 ± 19 (419–474) |
| V | 80 ±1.1 (79–83) | – |
| Stylet length | 15.8 ± 0.6 (15–16.8) | 14.9 ± 0.5 (14.1–16) |
| Dorsal gland opening from stylet base (DGO) | 2.8 ± 0.2 (2.5–3.1) | 2.8 ± 0.3 (2.3–3.1) |
| Anterior end to valve of median bulb | 53 ± 2.1 (50–57) | 50 ± 2 (48–53) |
| Anterior end to nerve ring | 65 ± 2.7 (61–69) | 62 ± 3.1 (58–67) |
| Anterior end to secretory-excretory pore | 81 ± 4.6 (71–88) | 73 ± 3.4 (69–78) |
| Anterior end to pharyngo-intestinal junction | 81 ± 4.5 (71–87) | 78 ± 5.1 (72–89) |
| Anterior end to end of pharyngeal gland | 129 ± 4 (121–136) | 117 ± 5.6 (110–129) |
| Pharyngeal gland overlap | 48 ± 3.2 (43–52) | 39 ± 4.4 (33–49) |
| Max body diam. | 21 ± 1.7 (18.7–23) | 16.6 ± 1 (15.1–18) |
| Vulval body diam. | 19 ± 1.4 (17–21.4) | – |
| Post-uterine sac (PUS) | 26 ± 3.5 (17.7–29) | – |
| Anal body diam. | 13.1 ± 1.1 (11.9–14.9) | 11 ± 0.6 (10.4–12.4) |
| Tail length | 30 ± 2.1 (27–33) | 24 ± 1.9 (22–27) |
| Tail annuli at ventral side | 23 ± 1.5 (21–25) | – |
| Spicule length | – | 15.2 ± 0.9 (13.6–16.3) |
| Gubernaculum length | – | 4.3 ± 0.3 (3.7–4.9) |
| PUS/Vulval body diam | 1.4 ± 0.2 (1–1.6) | – |
