Figure 1.

Figure 2.

Figure 3.

Figure 4.

Figure 5.

Figure 6.

The overlap ratio of the top 1% of scientists identified by different mutually reinforcing ranking algorithms_
| Algorithms | WHNR | TAMRR | Prank | MutualRank | MLMRJR |
|---|---|---|---|---|---|
| WHNR | 1 | 0.8113 | 0.6180 | 0.7843 | 0.7497 |
| TAMRR | 0.8113 | 1 | 0.6809 | 0.8126 | 0.8472 |
| Prank | 0.6180 | 0.6809 | 1 | 0.5901 | 0.6133 |
| MutualRank | 0.7843 | 0.8126 | 0.5901 | 1 | 0.8691 |
| MLMRJR | 0.7497 | 0.8472 | 0.6133 | 0.8691 | 1 |
The top 20 papers identified by different mutually reinforcing ranking algorithms_
| DOIs | Year | Ranking algorithms | ||||
|---|---|---|---|---|---|---|
| WHNR | MLMRJR | MutualRank | Prank | TAMRR | ||
| 10.1103/PhysRev.81.385 | 1951 | 1 | 88 | 79 | 45 | 24 |
| 10.1103/PhysRev.34.1293 | 1929 | 2 | 59 | 299 | 1 | 4 |
| 10.1103/PhysRev. 136.B864 | 1964 | 3 | 60 | 2 | 74 | 3 |
| 10.1103/PhysRev.73.679 | 1948 | 4 | 62 | 43 | 57 | 21 |
| 10.1103/PhysRev.47.777 | 1935 | 5 | 316 | 32 | 42 | 7 |
| 10.1103/PhysRevLett.77.3865 | 1996 | 6 | 6 | 3 | 1,354 | 14 |
| 10.1103/PhysRev. 131.2766 | 1963 | 7 | 85 | 40 | 141 | 41 |
| 10.1103/PhysRev.65.117 | 1944 | 8 | 141 | 47 | 8 | 10 |
| 10.1103/RevModPhys.15.1 | 1943 | 9 | 79 | 18 | 51 | 5 |
| 10.1103/PhysRev. 125.1067 | 1962 | 10 | 20 | 50 | 104 | 23 |
| 10.1103/PhysRev. 106.364 | 1957 | 11 | 65 | 242 | 23 | 27 |
| 10.1103/PhysRev. 109.193 | 1958 | 12 | 17 | 41 | 52 | 11 |
| 10.1103/PhysRev. 124.1866 | 1961 | 13 | 183 | 8 | 213 | 13 |
| 10.1103/PhysRevLett.19.1264 | 1967 | 14 | 45 | 15 | 65 | 8 |
| 10.1103/PhysRev. 109.1492 | 1958 | 15 | 258 | 21 | 64 | 18 |
| 10.1103/PhysRev.43.804 | 1933 | 16 | 98 | 370 | 3 | 15 |
| 10.1103/PhysRev.46.1002 | 1934 | 17 | 2,333 | 105 | 15 | 16 |
| 10.1103/PhysRev. 108.1175 | 1957 | 18 | 3 | 4 | 6 | 1 |
| 10.1103/PhysRev. 140.A1133 | 1965 | 19 | 35 | 1 | 54 | 2 |
| 10.1103/PhysRevB.23.5048 | 1981 | 20 | 16 | 5 | 392 | 12 |
Journal rankings based on different mutually reinforcing ranking algorithms_
| Journals | Ranking algorithms | ||||
|---|---|---|---|---|---|
| WHNR | MLMRJR | MutualRank | Prank | TAMRR | |
| Physical Review Letters | 1 | 1 | 1 | 1 | 1 |
| Physical Review B | 2 | 2 | 2 | 2 | 2 |
| Physical Review D | 3 | 3 | 4 | 3 | 3 |
| Physical Review A | 4 | 4 | 3 | 4 | 4 |
| Physical Review C | 5 | 5 | 6 | 6 | 5 |
| Physical Review E | 6 | 6 | 5 | 7 | 6 |
| Review of Modern Physics | 7 | 7 | 7 | 5 | 7 |
| Physical Review Special Topics-Accelerators and Beams | 8 | 8 | 8 | 8 | 8 |
| Physical Review Special Topics-Physics Education Research | 9 | 9 | 9 | 9 | 9 |
Hypothesis testing results_
| Hypothesis | Correlation Test | ||
|---|---|---|---|
| Correlation Coefficient | P-value | 95% Confidence Interval | |
| H1 | 0.3974 | 0.0010 | [0.3947, 0.4002] |
| H2 | 0.5341 | 0.0010 | [0.5317, 0.5362] |
| H3 | 0.5955 | 0.0010 | [0.5932, 0.5976] |
| H4 | 0.5295 | 0.0010 | [0.5265, 0.5323] |
| H5 | 0.2219 | 0.0010 | [0.2179, 0.2257] |
| H6 | 0.4248 | 0.0010 | [0.4214, 0.4286] |
| H7 | 0.7273 | 0.0130 | [0.0748, 1] |
| H8 | 0.7364 | 0.0140 | [0.1686, 0.9703] |
| H9 | 0.7360 | 0.0150 | [0.1336, 0.9721] |
The overlap ratio of the top 1% papers identified by different mutually reinforcing ranking algorithms_
| Algorithms | WHNR | TAMRR | Prank | MutualRank | MLMRJR |
|---|---|---|---|---|---|
| WHNR | 1 | 0.7911 | 0.6477 | 0.5852 | 0.6254 |
| TAMRR | 0.7911 | 1 | 0.6183 | 0.6803 | 0.7743 |
| Prank | 0.6477 | 0.6183 | 1 | 0.3821 | 0.5178 |
| MutualRank | 0.5852 | 0.6803 | 0.3821 | 1 | 0.6828 |
| MLMRJR | 0.6254 | 0.7743 | 0.5178 | 0.6828 | 1 |
The top 20 scientists identified by different mutually reinforcing ranking algorithms_
| Authors | Paper count | Ranking algorithms | ||||
|---|---|---|---|---|---|---|
| WHNR | MLMRJR | MutualRank | Prank | TAMRR | ||
| John C. Slater | 66 | 1 | 4 | 4 | 1 | 1 |
| G. Breit | 176 | 2 | 3 | 6 | 3 | 3 |
| Chen N. Yang | 105 | 3 | 9 | 8 | 7 | 9 |
| John H. Van Vleck | 63 | 4 | 36 | 24 | 20 | 12 |
| M. Gell-Mann | 38 | 5 | 19 | 25 | 14 | 15 |
| Richard P. Feynman | 34 | 6 | 26 | 20 | 13 | 13 |
| Hans A. Bethe | 101 | 7 | 7 | 7 | 10 | 5 |
| U. Fano | 83 | 8 | 46 | 18 | 183 | 18 |
| S. Weinberg | 133 | 9 | 2 | 3 | 15 | 6 |
| Robert S. Mulliken | 65 | 10 | 60 | 62 | 39 | 33 |
| Philip W. Anderson | 138 | 11 | 1 | 1 | 8 | 2 |
| Eugene P. Wigner | 46 | 12 | 20 | 12 | 2 | 7 |
| Julian S. Schwinger | 104 | 13 | 6 | 5 | 6 | 4 |
| J. Bardeen | 79 | 14 | 15 | 11 | 5 | 10 |
| Taekoon D. Lee | 189 | 15 | 11 | 17 | 16 | 14 |
| C. Kittel | 80 | 16 | 17 | 19 | 19 | 11 |
| James C. Phillips | 195 | 17 | 27 | 28 | 49 | 25 |
| W. Kohn | 115 | 18 | 5 | 2 | 22 | 8 |
| Geoffrey F. Chew | 85 | 19 | 22 | 32 | 36 | 31 |
| Bertrand I. Halperin | 185 | 20 | 13 | 9 | 63 | 16 |
The correlation between papers’ impact scores under different mutually reinforcing ranking algorithms_
| Algorithms | WHNR | TAMRR | Prank | MutualRank | MLMRJR |
|---|---|---|---|---|---|
| WHNR | 1 | 0.9277 | 0.7288 | 0.8454 | 0.8972 |
| TAMRR | 0.9277 | 1 | 0.731 | 0.9348 | 0.9777 |
| Prank | 0.7288 | 0.731 | 1 | 0.7836 | 0.7986 |
| MutualRank | 0.8454 | 0.9348 | 0.7836 | 1 | 0.9492 |
| MLMRJR | 0.8972 | 0.9777 | 0.7986 | 0.9492 | 1 |
The correlation between scientists’ impact scores under different mutually reinforcing ranking algorithms_
| Algorithms | WHNR | TAMRR | Prank | MutualRank | MLMRJR |
|---|---|---|---|---|---|
| WHNR | 1 | 0.8902 | 0.8077 | 0.9118 | 0.8502 |
| TAMRR | 0.8902 | 1 | 0.9372 | 0.9638 | 0.9762 |
| Prank | 0.8077 | 0.9372 | 1 | 0.8808 | 0.9276 |
| MutualRank | 0.9118 | 0.9638 | 0.8808 | 1 | 0.9476 |
| MLMRJR | 0.8502 | 0.9762 | 0.9276 | 0.9476 | 1 |
