Endocrine adverse effects of mono(2-ethylhexyl) phthalate and monobutyl phthalate in male pubertal rats

Karabulut, Gözde; Barlas, Nurhayat

doi:10.2478/aiht-2022-73-3617

Figures & Tables

Liver tissue photomicrographs in A) – the oil control group (×400 magnification); B and C – the group receiving MEHP dose of 100 mg/kg bw a day (×400 and ×200 magnification, respectively); D – the group receiving MEHP dose of 200 mg/kg bw a day (×200 magnification); E – the group receiving MEHP dose of 400 mg/kg bw a day (×200 magnification): (F) 200 mg/kg bw a day of monobutyl phthalate (MBP) (×400), (G) 400 mg/kg bw a day of MBP (×400). c – congestion; cd – cytoplasmic dissolution; mci – mononuclear cell infiltration; sd – sinusoidal degeneration

Kidney tissue photomicrographs in A – the oil control group (×400 magnification); B – the group receiving MEHP dose of 100 mg/kg bw a day (×200 magnification); C – the group receiving MEHP dose of 200 mg/kg bw a day (×200 magnification); D – the group receiving MBP dose of 200 mg/kg bw a day (×400 magnification); E – the group receiving MBP dose of 400 mg/kg bw a day (×400 magnification). ag – athropic glomerulus; c – congestion; gd – glomerular degeneration; pvl – parietal and visceral leaves; td – tubular degeneration

Pancreas tissue photomicrographs in A – the oil control group (×400 magnification); B – the group receiving MEHP dose of 200 mg/kg bw a day (×400 magnification); C – the group receiving MEHP dose of 400 mg/kg bw a day (×400 magnification); D – the group receiving MBP dose of 200 mg/kg bw a day (×200 magnification); E – the group receiving MBP dose of 400 mg/kg bw a day (×200 magnification). c – congestion; dli – degeneration of Langerhans islets

Biochemical markers measured in the oil control and experimental groups treated with mono(2-ethylhexyl) phthalate (MEHP)

Parameters	Control	MEHP (mg/kg bw a day)
Parameters	Control	25	50	100	200	400
ALT (IU/L)	45.65±17.41	50.3±0.22	55.4±0.11	65.25±15.99^a,b	85.63±10.72^a,b,c	96.91±7.82^a,b,c,d
AST (IU/L)	110.1±101.6	115.2±15.12	120.45±22.12^d,e,f	139.8±88.9^a	182.6±36.9^a,b	268.3±110.6^a,b,c
Triglycerides (mg/dL)	945.8±704.6	1050.27±5.43	1210.12±3.54^a,d	1450.8±294.5^a	1650.3±250^a,b	1702.6±266.4^a,b,c
Glucose (IU/L)	191.5±61	201.27±13.07	205.17±0.6	211.1±33.5^a,e,f	251.1±19.3^a,b	301.6±43.5^a,b,c
Total protein (g/dL)	8.6±0.8	8.3±2.34	8.22±3.34	8.5±2.6	6.8±0.3^a,b,c,d	6.6±0.4^a,b,c,d
Albumin (g/dL)	32.35±2.73	29.8±4.44	29.8±1.14	27.93±1.34	21.03±1.88^a,b,c,d	18.66±1.53^a,b,c,d
Creatinine (mg/dL)	0.46±0.22	0.47±8.91	0.46±6.45	0.49±0.25	0.48±0.16	0.45±0.15
Urea (mg/dL)	14.8±3.3	14.7±4.12	13.09±2.44	13.7±1.8	12.3±8.3	11.5±2^a,b,c

Insulin levels measured in oil control and experimental groups treated with mono(2-ethylhexyl) phthalate (MEHP)

Groups	Control	MEHP (mg/kg bw a day)
Groups	Control	25	50	100	200	400
Insulin (ng/mL)	1.43±0.48	1.35±0.12	1.32±0.1	1.24±1.03^a	0.77± 0.82^a,b,c,d	0.69±0.61^a,b,c,d

Food and water consumption by rats in the oil control and experimental groups treated with mono(2-ethylhexyl) phthalate (MEHP)

Groups	Control	MEHP (mg/kg bw a day)
Groups	Control	25	50	100	200	400
Food (g)	10.70±3.60	11.12±1.01	12.14±2.29	15.43±4.37	20.06±6.51^a,b,c,f	30.05±5.72^a,b,c,d,e
Water (mL)	9.82±2.76	10.21±0.12	10.32±0.78	11.63±2.95	11.53±1.39	12.13±3.81

Body and absolute and relative organ weights of rats in the oil control and experimental groups treated with monobutyl phthalate (MBP)

Groups	Control	MBP (mg/kg bw a day)
Groups	Control	25	50	100	200	400
Baseline body weight (g)	220.8±1.0	220.4±0.1	221.3±0.2	224.4±0.8	219.7±0.1	217.9±0.1
Final body weight (g)	330.9±1.2	331.02±0.8	332.01±0.3	323.2±0.1	330.4±0.4	350.7±0.1
Weight gain %	50.02±0.2	50.09±0.7	51.07±0.8	50.09±0.8	54.01±0.2	55.06±0.3
Liver
Absolute weight (g)	10.5±1.0	11.5±0.1	12.4±0.3	17.4±0.9^a,b	17.9±0.1^a,b	18.44±0.1^a,b,c
Relative weight (mg/g)	34.8±1.2	33.3±1.3	33.1±1.2	32.8±0.7	33.9±0.4	34.1±1.1
Kidney
Absolute weight (g)	1.07±0.1	1.09±1.1	1.10±1.2	1.09±0.9	1.10±0.1	1.11±0.1
Relative weight (mg/g)	3.2±0.1	3.1±0.1	3.2±0.3	3.1±0.2	3.1±0.1	3.1±0.2
Pancreas
Absolute weight (g)	0.253±0.1	0.245±0.4	0.240±0.3	0.220±0.2	0.210±0.3	0.201±0.1^a,b
Relative weight (mg/g)	0.74±0.1	0.73±0.1	0.73±0.1	0.71±0.2	0.68±0.3^a,b,c,d	0.66±0.5^a,b,c,d

Body and absolute and relative organ weights of rats in the oil control and experimental groups treated with mono(2-ethylhexyl) phthalate (MEHP)

Groups	Control	MEHP (mg/kg bw a day)
Groups	Control	25	50	100	200	400
Baseline body weight (g)	220.8±1.0	219.5±0.2	221.1±0.1	222.3±0.9	217.8±0.1	218.9±0.1
Final body weight (g)	330.9±1.2	340.4±0.3	340.3±0.5	333.2±0.7	340.5±0.4	348.7±1.1
Weight gain %	50.02±0.2	52.03±0.5	51.02±0.1	51.09±0.8	55.01±0.3	54.06±0.4
Liver
Absolute weight (g)	10.5±1.0	12.4±1.2	14.2±0.1	16.5±0.9^a	16.9±0.1^a	17.48±0.1^a
Relative weight (mg/g)	34.8±1.2	32.1±0.2	33.1±0.4	32.7±0.7	32.9±0.4	33.1±1.1
Kidney
Absolute weight (g)	1.07±0.1	1.07±0.1	1.09±0.2	1.09±0.9	1.09±0.2	1.10±0.1
Relative weight (mg/g)	3.2±0.1	3.1±0.2	3.2±0.2	3.1±0.2	3.1±0.1	3.0±0.2
Pancreas
Absolute weight (g)	0.253±0.1	0.240±0.2	0.242±0.4	0.212±0.2	0.198±0.3^a,b,c	0.160±0.4^a,b,c,d
Relative weight (mg/g)	0.74±0.1	0.73±0.2	0.72±0.1	0.71±0.2	0.68±0.3^a,b,c,d	0.59±0.5^a,b,c,d

Biochemical markers measured in the oil control and experimental groups treated with monobutyl phthalate (MBP)

Parameters	Control	MBP (mg/kg bw a day)
Parameters	Control	25	50	100	200	400
ALT (IU/L)	45.65±17.41	47.26±0.22	50.62±0.11	55.25±14.99^a	76.63±19.72^a,b,c	82.91±6.82^a,b,c,d
AST (IU/L)	110.1±101.6	120.9±15.12	135.66±22.12	159.8±65.9^a	191.6±36.9^a,b	276.3±90.6^a,b,c,d
Triglycerides (mg/dL)	945.8±704.6	960.8±5.43	1100.9±3.54	1550.8±294^a,b	1850.3±250^a,b,c	1820.4±116.4^a,b,c
Glucose (IU/L)	191.5±61	220.27±13.07	251.17±0.6	291.1±22.5^a	351.1±18.3^a,b	401.6±41.5^a,b,c
Total Protein (g/dL)	8.6± 0.8	8.3±2.34	8.2±3.34	8.1±2.6	7.1±0.3^ab	6.4±0.4^a,b,c
Albumin (g/dL)	32.35±2.73	31.9±4.44	31.2±1.14	29.92±1.32	22.03±1.98^a,b,c	21.33±1.43^a,b,c
Creatinine (mg/dL)	0.46±0.22	0.47±8.91	0.48±6.45	0.48±0.15	0.38±0.17	0.35±0.14^a,b,c
Urea (mg/dL)	14.8±3.3	14.5±4.12	14.3±2.44	14.8±1.8	13.2±8.3	11.3±2^a,b,d

Incidence of exposure-related histopathologic lesions observed in oil control and experimental groups treated with monobutyl phthalate (MBP)

Parameters / Groups	Control	MBP (mg/kg bw a day)
Parameters / Groups	Control	25	50	100	200	400
Liver
Sinusoidal degeneration	0/6	0/6	1/6	4/6*	4/6*	6/6*
Congestion	1/6	2/6	2/6	4/6*	3/6	5/6*
Cytoplasmic dissolution	0/6	1/6	1/6	3/6	3/6*	3/6
Mononuclear cell infiltration	1/6	0/6	2/6	2/6	5/6*	5/6*
Kidney
Glomerulus degeneration	0/6	0/6	1/6	3/6	4/6*	5/6*
Congestion	1/6	2/6	2/6	4/6*	3/6	6/6*
Cytoplasmic dissolution	0/6	1/6	1/6	1/6	1/6	2/6
Mononuclear cell infiltration	1/6	0/6	2/6	1/6	1/6	1/6
Pancreas
Degeneration of pancreatic cells	0/6	0/6	1/6	2/6	5/6*	6/6*
Congestion	1/6	1/6	1/6	2/6	2/6	5/6*

Incidence of exposure-related histopathological lesions observed in oil control and experimental groups treated with mono(2-ethylhexyl) phthalate (MEHP)

Parameters / Groups	Control	MEHP (mg/kg bw a day)
Parameters / Groups	Control	25	50	100	200	400
Liver
Sinusoidal degeneration	0/6	0/6	1/6	4/6*	5/6*	6/6*
Congestion	0/6	1/6	1/6	5/6*	3/6	5/6*
Cytoplasmic dissolution	0/6	1/6	1/6	1/6	4/6*	2/6
Mononuclear cell infiltration	0/6	0/6	1/6	4/6*	5/6*	5/6*
Kidney
Glomerulus degeneration	0/6	0/6	1/6	3/6	4/6	6/6*
Congestion	1/6	2/6	2/6	4/6*	3/6	5/6*
Cytoplasmic dissolution	0/6	1/6	1/6	3/6	3/6	3/6
Mononuclear cell infiltration	1/6	0/6	2/6	1/6	2/6	1/6
Pancreas
Degeneration of pancreatic cells	0/6	0/6	1/6	4/6*	4/6*	6/6*
Congestion	1/6	1/6	2/6	4/6*	3/6	5/6*

Food and water consumption by rats in the oil control and experimental groups treated with monobutyl phthalate (MBP)

Groups	Control	MBP (mg/kg bw a day)
Groups	Control	25	50	100 200	400
Food (g)	10.70±3.60	12.18±1.03	13.67±2.32	14.23±4.37 18.07±6.51^a	23.10±5.72^a,b,c,d
Water (mL)	9.82±2.76	10.01±0.54	10.34±0.33	10.23±2.95 12.53±1.39	13.53±3.81

Haematological parameters measured in the oil control and experimental groups treated with mono(2-ethylhexyl) phthalate (MEHP)

Parameters	Control	MEHP (mg/kg bw a day)
Parameters	Control	25	50	100	200	400
Leukocytes (mm³)	2.55±1.43	2.50±0.22	2.53±0.11	2.98±2.34	2.63±1.11	1.19±0.17^a,b,c,d,e
Lymphocytes (%)	68.50±16.17	68.50±15.12	69.45±22.12	70.83±21.34	65.42±8.39	78.41±16.90
Monocytes (%)	11.17±5.40	10.27±5.43	9.12±3.54	11.40±8.42	10.30±1.97	4.40±0.11^a,b,c,d,e
Neutrophils (%)	19.27±11.06	18.27±13.07	20.17±0.6	17.73±13.12	24.28±6.89	17.48±12.79
Erythrocytes (mm³)	13.22±3.53	14.23±2.34	14.22±3.34	11.6±2.68	13.3±1.76	8.26±0.68
MCV (fL)	27.8±5.34	29.8±4.44	28.8±1.14	29.41±1.13	25.78±3.89	53.12±2.89^a,b,c,d,e
Haematocrit (%)	35.27±8.18	33.17±8.91	34.56±6.45	33.6±6.06	27.1±6.29	39.27±1.62
MCH (pg)	7.87±4.52	8.77±4.12	9.01±2.44	8.83±3.38	11.6±11.24	14.9±1.24
MCHC (g/dL)	26.75±8.78	25.15±11.22	28.65±7.55	29.8±9.16	23.05±6.05	28.07±1.06
Haemoglobin (g/dL)	8.92±1.26	8.92±0.1	8.44±1.77	8.50±1.16	8.05±0.5	6.33±0.22^a,b,c,d,e
Thrombocytes (mm³)	3287.83±1276.73	3367.83±1131.02	3266.83±1144.03	3299.33±2483.02	2265±1567.18	2764.17±1876.21
PCT (%)	3.92±1.45	4.62±1.76	4.12±1.22	4.5±2.31	3.96±1.72	4.01±1.42

Antibody levels measured in oil control and experimental groups treated with mono(2-ethylhexyl) phthalate (MEHP) and monobutyl phthalate (MBP)

Groups	Islet cell antibody (ICA)	Insulin antibody (IAA)
Control	(-)	(-)
MEHP (mg/kg bw a day)
25	(-)	(-)
50	(-)	(-)
100	(-)	(-)
200	(-)	(-)
400	(-)	(-)
MBP (mg/kg bw a day)
25	(-)	(-)
50	(-)	(-)
100	(-)	(-)
200	(-)	(-)
400	(-)	(-)

Insulin levels measured in oil control and experimental groups treated with monobutyl phthalate (MBP)

Groups	Control	MBP (mg/kg bw a day)
Groups	Control	25	50	100	200	400
Insulin (ng/mL)	1.43±0.48	1.40±0.70	1.38±0.60	1.33±1.01 0.81	±0.71^a,b,c,d	0.80±0.51^a,b,c,d

Haematological parameters measured in the oil control and experimental groups treated with monobutyl phthalate (MBP)

Parameters	Control	MBP (mg/kg bw a day)
Parameters	Control	25	50	100	200	400
Leukocytes (mm³)	2.55±1.43	2.30±2.14	2.55±0.84	2.58±2.34	2.83±1.11	2.19±0.39
Lymphocytes (%)	68.50±16.17	67.51±17.17	70.60±26.01	71.83±21.34	72.42±8.39	73.41±16.90
Monocytes (%)	11.17±5.40	12.17±4.11	11.21±4.39	12.20±9.41	11.30±1.97	9.33±0.10
Neutrophils (%)	19.27±11.06	18.11±9.87	18.44±8.77	18.73±14.22	19.19±6.89	18.48±12.79
Erythrocytes (mm³)	13.22±3.53	12.12±3.21	13.01±1.21	12.6±2.68	13.3±1.76	12.26±0.68
MCV (fL)	27.8±5.34	28.9±4.53	28.8±1.01	28.42±2.13	29.78±3.89	62.11±1.89^a,b,c,d,e
Haematocrit (%)	35.27±8.18	34.10±1.21	35.09±5.23	34.7±6.06	37.1±6.29	38.27±3.65
MCH (pg)	7.87±4.52	8.17±2.33	8.41±1.43	7.93±3.39	9.6±11.24	8.9±1.24
MCHC (g/dL)	26.75±8.78	27.15±5.56	27.31±2.56	27.2±9.16	25.05±6.05	26.07±1.06
Haemoglobin (g/dL)	8.92±1.26	9.02±0.26	9.98±0.26	9.5±1.16	9.02±1.6	6.01±0.93^a,b,c,d,e
Thrombocytes (mm³)	3287.83±1276.7	3311.83±1222.01	3317.02±1143.3	3309.33±2483.0	3266±1598.1	3765.17±1659.2
PCT (%)	3.92±1.45	3.81±1.11	4.01±0.22	4.7±3.34	3.87±1.89	3.51±1.42
