Values of the medium parameters (Bartlewska 2009)_
| Index | 1 | 2 | 3 | 4 | 5 | 6 | 7 |
|---|---|---|---|---|---|---|---|
| Area | R01, R02, R04 | R05, R06, R08 | R09, R10, R21, R22 | R11, R12, R19, R20 | R13, R14, R17, R18 | R15, R16 | R03, R07 |
| j (°) | 35 | 32 | 25 | 12 | 18 | 16 | |
| c (Pa) | 1.00E+03 | 1.00E+04 | 1.00E+04 | 1.00E+04 | 1.00E+04 | 5.00E+03 | |
| k (m/s) | 1.00E−06 | 5.00E−07 | 2.00E−07 | 8.00E−08 | 5.00E−08 | 1.00E−08 | 1.00E−04 |
| N (Pa) | 9.50E+08 | 8.55E+07 | 9.50E+06 | 7.60E+06 | 4.75E+06 | 2.85E+06 | |
| A (Pa) | 2.20E+09 | 1.98E+08 | 2.20E+07 | 1.76E+07 | 1.10E+07 | 6.60E+06 | |
| R (Pa) | 5.00E+09 | 4.50E+08 | 5.00E+07 | 4.00E+07 | 2.50E+07 | 1.50E+07 | |
| H (Pa) | 2.50E+09 | 2.25E+08 | 2.50E+07 | 2.00E+07 | 1.25E+07 | 7.50E+06 | |
| n0 (−) | 0.25 | 0.22 | 0.35 | 0.33 | 0.30 | 0.30 | |
| G (N/m3) | 2.50E+04 | 2.40E+04 | 2.40E+04 | 2.35E+04 | 2.35E+04 | 2.35E+04 | |
| W (N/m3) | 1.00E+04 | 0.00 | |||||
| α (−) | 1.00 | 1.00 | 1.00 | 1.00 | 1.00 | 1.00 | |
| ηs | 2.50E+06 | 1.98E+05 | 2.50E+04 | 1.76E+04 | 1.10E+04 | 6.60E+03 | |
| λs | 1.00E+07 | 9.00E+05 | 1.00E+05 | 8.00E+04 | 5.00E+04 | 3.00E+04 | |
