Deformation analysis in central west Bulgaria using triangulation and GPS data

Figures & Tables

ST	V_x	m_x	V_y	m_y	V_z	m_z	V_n	m_n	V_e	m_e
	[mm/y]	[mm]	[mm/y]	[mm]	[mm/y]	[mm]	[mm/y]	[mm]	[mm/y]	[mm]
81	0.6	0.4	1.3	0.5	-2.5	0.4	-2.6	0.5	0.9	0.5
82	0.6	0.4	1.4	0.5	-2.7	0.4	-2.7	0.5	1.0	0.5
83	0.5	0.4	1.8	0.6	-2.9	0.4	-2.9	0.6	1.4	0.6
17	0.6	0.5	2.3	0.7	-3.2	0.5	-3.3	0.6	1.9	0.7
12	0.7	0.4	-0.3	0.4	-1.6	0.4	-1.6	0.5	-0.7	0.5
11	0.4	0.5	1.5	0.6	-2.5	0.5	-2.5	0.6	1.1	0.7
26	1.4	0.6	-1.3	0.4	-1.5	0.6	-1.6	0.2	-1.8	0.3
16	0.8	0.3	0.5	0.4	-2.2	0.3	-2.3	0.4	0.1	0.4
VERI	1.2	0.1	0.0	0.1	-2.2	0.1	-2.3	0.4	-0.5	0.3
PLA1	1.0	0.1	0.1	0.1	-2.1	0.1	-2.2	0.3	-0.4	0.2
BUHO	0.8	0.2	1.4	0.1	-2.8	0.2	-2.9	0.5	0.9	0.4
LOZE	0.9	0.3	0.6	0.1	-2.4	0.3	-2.5	0.5	0.2	0.4
VLAD	0.6	0.2	1.8	0.1	-2.9	0.1	-2.9	0.4	1.3	0.3
BREZ	0.4	0.2	1.3	0.1	-2.4	0.2	-2.4	0.5	1.1	0.4
SLIV	0.4	0.2	1.8	0.1	-2.7	0.2	-2.8	0.5	1.5	0.4
