Fig. 1
Nine MIRU-VNTR patterns identified among 54 strains
| No | Spoligotype | MIRU-VNTR type | LOCUS | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4 | 10 | 16 | 26 | 31 | 40 | 424 | 577 | 2165 | 2401 | 3690 | 4156 | 2163 | 1955 | 4052 | |||
| 1 | BOVIS 595 | 424722356422327 | 4 | 2 | 4 | 7 | 2 | 2 | 3 | 5 | 6 | 4 | 2 | 2 | 3 | 2 | 7 |
| 2 | BOVIS 595 | 424722357422325 | 4 | 2 | 4 | 7 | 2 | 2 | 3 | 5 | 7 | 4 | 2 | 2 | 3 | 2 | 5 |
| 3 | BOVIS 595 | 425532355422434 | 4 | 2 | 5 | 5 | 3 | 2 | 3 | 5 | 5 | 4 | 2 | 2 | 4 | 3 | 4 |
| 4 | BOVIS 595 | 424721374422525 | 4 | 2 | 4 | 7 | 2 | 1 | 3 | 7 | 4 | 4 | 2 | 2 | 5 | 2 | 5 |
| 5 | BOVIS 595 | 424732357422325 | 4 | 2 | 4 | 7 | 3 | 2 | 3 | 5 | 7 | 4 | 2 | 2 | 3 | 2 | 5 |
| 6 | BOVIS 595 | 424731357432215 | 4 | 2 | 4 | 7 | 3 | 1 | 3 | 5 | 7 | 4 | 3 | 2 | 2 | 1 | 5 |
| 7 | BOVIS 595 | 424832354422437 | 4 | 2 | 4 | 8 | 3 | 2 | 3 | 5 | 4 | 4 | 2 | 2 | 4 | 3 | 7 |
| 8 | BOVIS 595 | 424731374452525 | 4 | 2 | 4 | 7 | 3 | 1 | 3 | 7 | 4 | 4 | 5 | 2 | 5 | 2 | 5 |
| 9 | BOVIS 595 | 424731374422525 | 4 | 2 | 4 | 7 | 3 | 1 | 3 | 7 | 4 | 4 | 2 | 2 | 5 | 2 | 5 |
Molecular clusters identified among 50 strains by spoligotypes and MIRU-VNTR patterns
| No | Spoligotype | MIRU-VNTR (number of strains) | Number of strains in the cluster | Number of herds with strains in the cluster |
|---|---|---|---|---|
| I | BOVIS 5951 SB22202 | 425532355422434 (21) | 21 | 2 |
| II | BOVIS 5951 SB22202 | 424722357422325 (18) 424732357422325 (9) | 27 | 2 |
| III | Not registered | 424731374452525 (1) 424731374422525 (1) | 2 | 2 |
