Figure 1

Figure 2

Figure 3

Figure 4

Percentage of apoptotic cells in HeLa and MCF-7 human cancer cell lines treated with [Bmim]Br and [Bpy]Br
| Treatment type | Cell type | Concentration (μmol/L) | Cell percentage (%) | |||
|---|---|---|---|---|---|---|
| Living cells | Early apoptotic | Late apoptotic | Dead cells | |||
| [Bmim]Br | HeLa | 0 | 95.50 | 1.45 | 2.45 | 0.60 |
| 100 | 79.80* | 5.50* | 14.05* | 0.65 | ||
| 1500 | 47.53* | 8.52* | 42.15* | 1.79* | ||
| MCF-7 | 0 | 90.40 | 1.80 | 6.95 | 0.85 | |
| 100 | 61.28* | 2.00 | 35.33* | 1.40* | ||
| 1500 | 41.88* | 5.00* | 50.62* | 2.50* | ||
| [Bpy]Br | HeLa | 100 | 79.60* | 4.93* | 15.13* | 0.35 |
| 1000 | 38.32* | 8.98* | 50.90* | 1.80* | ||
| MCF-7 | 100 | 55.79* | 4.47* | 36.68* | 1.05 | |
| 1000 | 33.86* | 3.94* | 60.63* | 1.57* | ||
Comparison of [Bmim]Br and [Bpy]Br half-maximal inhibition (IC50) in different human cell lines
| Cell type | IC50 (μmol/L) | ||
|---|---|---|---|
| [Bmim]Br | [Bpy]Br | ||
| HeLa | 841.86±21.03 | 341.74±13.61* | |
| MCF-7 | 538.38±10.54 | 333.27±19.18* | |
| HEK293-T | 654.78±22.6 | 328.98±26.49* | |
Names and general structures of the tested ionic liquids
| Name | Abbreviation | Structure |
|---|---|---|
| 1-butyl-3-methylimidazolium bromide | [Bmim][Br] | |
| 1-butyl-3-methylpyridinium bromide | [Bpy][Br] |
