Figure 1

Figure 2

Environmental parameters measured during the spring and autumn of 2009 in the four identified habitat types H – helophyte zone; P – pleustophyte zone; M – mixed vegetation zone (pleustophytes, nymphaeids, and elodeids); O – open water zone; Mean±SE; ANOVA results (*statistically significant)
| Seasons | Environmental parameters | H | P | M | O | Habitat types (p) |
|---|---|---|---|---|---|---|
| Spring | Depth (m) | 0.3±0.1 | 0.5±0.2 | 0.7±0.2 | 0.5±0.4 | 0.846 |
| Water temperature (°C) | 17.5±4.8 | 18.4±5.6 | 18.9±3.7 | 17.8±4.1 | 0.734 | |
| Dissolved oxygen (%) | 42.7±12.8 | 21.5±11.8 | 23.4±12.1 | 53.8±21.7 | 0.037* | |
| pH | 7.5±0.7 | 7.6±0.8 | 7.6±0.9 | 8.1±0.4 | 0.627 | |
| Conductivity (µS cm ) | 322.8±112 | 312.4±105 | 285.7±95 | 312.4±131 | 0.728 | |
| Chlorophyll a (µg l ) | 25.8±12.6 | 28.4±13.5 | 27.6±17.2 | 16.7±6.2 | 0.157 | |
| Autumn | Depth (m) | 0.4±0.2 | 0.6±0.2 | 0.6±0.2 | 0.5±0.2 | 0.748 |
| Water temperature (°C) | 22.5±4.8 | 24.4±5.6 | 25.1±2.1 | 23.2±3.5 | 0.648 | |
| Dissolved oxygen (%) | 17.2±9.8 | 18.2±5.4 | 17.8±4.6 | 34.2±11.2 | 0.031* | |
| pH | 7.5±0.7 | 7.6±0.8 | 7.6±0.9 | 8.1±0.4 | 0.681 | |
| Conductivity (µS cm ) | 312.8±112 | 308.7±56 | 304.8±85 | 311.2±147 | 0.816 | |
| Chlorophyll a (µg l ) | 36.3±14.7 | 32.8±21.7 | 33.1±14.1 | 22.7±9.7 | 0.213 |
Two-way ANOVA results for the relationship between the season (spring and autumn) and the habitat and the zooplankton density
| Factors | n | d.f. | F | P |
|---|---|---|---|---|
| Season | 119 | 1 | 0.074 | 0.724 |
| Habitat | 119 | 1 | 7.906 | 0.008 |
| Season × Habitat | 238 | 1 | 0.000 | 0.895 |
List of zooplankton species found in the four identified habitat types during the spring and autumn of 2009
| Taxa | Spring | Autumn | ||||||
|---|---|---|---|---|---|---|---|---|
| H | P | M | O | H | P | M | O | |
| Rotifers | ||||||||
| Anuraeopsis fissa | + | + | + | + | ||||
| Brachionus angularis | + | + | + | + | + | |||
| Brachionus quadridentatus | + | + | + | + | + | |||
| Colurella obtusa | + | + | + | |||||
| Euchlanis dilatata | + | |||||||
| Keratella valga | + | + | + | |||||
| Lecane ludwigii | + | + | ||||||
| Lepadella oblongata | + | + | + | + | + | |||
| Monostyla bulla | + | + | ||||||
| Monostyla closterocerca | + | |||||||
| Monostyla hamata | + | + | + | |||||
| Monostyla pygmaea | + | + | + | + | + | + | ||
| Monostyla furgata | + | |||||||
| Mytilina ventralis | + | + | + | |||||
| Monomata grandis | + | + | ||||||
| Philodina roseola | + | |||||||
| Platyias patulus | + | + | + | |||||
| Ploesoma tetractis | + | |||||||
| Ploesoma truncatum | + | + | + | + | ||||
| Polyarthra remata | + | + | + | + | + | |||
| Squatinella mutica | + | + | + | + | ||||
| Testudinella patina | + | + | ||||||
| Trichocerca pusilla | + | + | + | |||||
| Trichocerca rattus | + | |||||||
| Trichocerca gracilis | + | + | ||||||
| Trichotria pocillum | + | + | ||||||
| Trichotria tetractis | + | + | ||||||
| Cladocerans | ||||||||
| Acropenus harpae | + | |||||||
| Alona guttata | + | + | + | |||||
| Camptocercus rectirostris | + | |||||||
| Chydorus sphaericus | + | + | ||||||
| Coronatella rectangula | + | + | + | + | + | + | + | |
| Diaphanosoma brachyurum | + | + | ||||||
| Graptoleberis testudinaria | + | |||||||
| Iltocryptus spinifer | + | |||||||
| Pleuxus denticulata | + | + | + | |||||
| Pleuxus laevis | + | |||||||
| Simocephalus exponisus | + | + | ||||||
| Simocephalus vetulus | + | + | + | + | ||||
| Scapholeberis kingi | + | + | ||||||
| Copepods | ||||||||
| Mesocyclops leuckarti | + | + | + | + | + | |||
| Thermocyclops crassus | + | + | + | + | + | |||
| Thermocyclops taihokuensis | + | + | + | |||||
Species names of aquatic macrophytes and dry weight along with the number of samples collected in spring and autumn in the four identified habitat types
| Habitat types | Species of aquatic macrophytes | Sampling point | Dry weight (g dw m−2) | |
|---|---|---|---|---|
| Spring | Autumn | |||
| Helophytes zones | Phragmites communis (TRIN.) | 32 | 22.7±6.7 | 29.7±5.7 |
| Paspalum distichum var. indutum Shinners | 12.3±5.4 | 16.4±9.4 | ||
| Pleustophytes zones | Spirodela polyrhiza (L.) | 27 | 12.6±6.4 | 21.4±8.7 |
| Salvinia natans (L.) ALL | 8.2±2.4 | 14.8±4.4 | ||
| Mixed plants zones | Spirodela polyrhiza (L.) | 30 | 15.8±7.1 | 28.7±6.1 |
| Salvinia natans (L.) | 6.7±4.7 | 21.8±9.8 | ||
| Ceratophyllum demersum (L.) | 23.4±9.4 | 35.7±11.7 | ||
| Potamogeton crispus (L.) | 25.7±6.8 | 36.7±8.7 | ||
| Najas graminea (L.) | 13.4±5.4 | 21.7±6.9 | ||
| Open water zones | - | 30 | - | - |
