Anatomy of the vasculature supplying hepatobiliary structures and celiac trunk branching patterns in the Thai population

Asian Biomedicine

Volume 12 (2018): Issue 4 (August 2018)

By: Natcha Nateniyom, Thanasil Huanmanop, Sithiporn Agthong and Vilai Chentanez

Open Access

|Sep 2019

Figures & Tables

Type I celiac branching pattern. AA, abdominal aorta; CHA, common hepatic artery; CT, celiac trunk; LGA, left gastric artery; SA, splenic artery

Type III celiac branching patterns. AA, abdominal aorta; CHA, common hepatic artery; CT, celiac trunk; DPA, dorsal pancreatic artery; LGA, left gastric artery; SA, splenic artery; SMA, superior mesenteric artery

Type V celiac branching patterns. AA, abdominal aorta; CBD, common bile duct; CHA, common hepatic artery; CHD, common hepatic duct; CT, celiac trunk; GDA, gastroduodenal artery; LHA, left hepatic artery; LGA, left gastric artery; rRHA, replaced right hepatic artery; SA, splenic artery

Type XIII celiac branching patterns. CHA, common hepatic artery; CT, celiac trunk; GDA, gastroduodenal artery; LGA, left gastric artery; LtIP, left inferior phrenic artery; rLHA, replaced left hepatic artery; rRHA, replaced right hepatic artery; SA, splenic artery

Special variation of the right hepatic artery. Both the rRHA and the aRHA arose from the CHA. aRHA, accessory right hepatic artery; CHA, common hepatic artery; CT, celiac trunk; GDA, gastroduodenal artery; LGA, left gastric artery; RGA, right gastric artery; rLHA, replaced left hepatic artery; rRHA, replaced right hepatic artery; SA, splenic artery

Special variation of the left hepatic artery. rLHA arose from CHA. aLHA arose from LGA. aLHA, accessory left hepatic artery; CHA, common hepatic artery; GDA, gastroduodenal artery; LGA, left gastric artery; rLHA, replaced left hepatic artery; rRHA, replaced right hepatic artery

Special variation of the CA. This case had double CAs with different relations to CBD and CHD. First CA (CA-1) arose from RHA passing posterior to CBD and CHD, while another CA (CA-2) arose from GDA passing anterior to CBD and CHD. CA, cystic artery; CBD, common bile duct; CD, cystic duct; CHD, common hepatic duct; GDA, gastroduodenal artery; RHA, right hepatic artery

The branching patterns of celiac trunk

Classification		Branching pattern	Number of branches	Number of cases (n = 100)	Remark
Type	I	SA + CHA	2	1	LGA from AA
Type	II	LGA + SA + CHA	3	70
Type	III	LGA + SA + DPA	3	1	CHA from SMA
Type	IV	SA + CHA + LtIP	3	1	LGA from AA
Type	V	LGA + SA + CHA + rRHA	4	6
Type	VI	LGA + SA + CHA + DPA	4	4
Type	VII	LGA + SA + CHA + SGA	4	1
Type	VIII	LGA + SA + CHA + LtIP	4	5
Type	IX	LGA + SA + CHA + common trunk of LtIP and RtIP	4	2
Type	X	LGA + SA + CHA + RtIP	4	4
Type	XI	LGA + SA + CHA + LtIP + RtIP	5	2
Type	XII	LGA + SA + CHA + rRHA + RtIP	5	1
Type	XIII	LGA + SA + CHA + rRHA + LtIP	5	1
Type	XIV	LGA + SA + CHA + DPA + LtIP	5	1

The origin of the RHA and the LHA

		Origin
Description	Number of cases n = 100	PHA	CHA	CT	SMA	AA	LGA
		n	n	n	n	n	n
RHA	67	67
RHA + aRHA	2				1 (aRHA)	1 (aRHA)
rRHA	30		13	8	9
rRHA (from CHA) + aRHA	1		1 (aRHA)
LHA	66	66
LHA + aLHA	3		2 (aLHA)				1 (aLHA)
rLHA	30		29				1
rLHA (from CHA) + aLHA	1						1 (aLHA)

The origin and type of CA

	Type of CA
Origin	Single n (%)	Double n (%)	Total number of CA n = 102 (%)
RHA	78 (76)	3 (3)	81 (79)
rRHA	9 (9)	4 (4)	13 (13)
aRHA	2 (2)	0	2 (2)
LHA	1 (1)	0	1 (1)
CHA	2 (2)	0	2 (2)
GDA	1 (1)	1 (1)	2 (2)
PHA	1 (1)	0	1 (1)
Total number of CA	94 (92)	8 (8)	102 (100)

The relation of the CA to the CBD and CHD

Classification of the CA	Relation to the CBD and CHD
	Passed anteriorly n (%)	Passed posteriorly n (%)	1 anterior, 1 posterior n (%)	Total number of cases (n = 98) n (%)
Single	38 (39)	56 (57)	None	94 (96)
Double	1 (1)	2 (2)	1 (1)	4 (4)
Total number of case, n (%)	39 (40)	58 (59)	1 (1)	98 (100)

DOI: https://doi.org/10.1515/abm-2019-0016 | Journal eISSN: 1875-855X | Journal ISSN: 1905-7415

Journal RSS Feed

Language: English

Page range: 161 - 167

Published on: Sep 25, 2019

Published by: Chulalongkorn University
